Interface

Profinet

Output current, maximum 2 A

Fast Startup (FSU) Yes

Display

No

Working Voltage Ub

18 - 30.2 VDC

Interface (COM 1)

M12x1 socket, 4-pin, D-code

Interface (COM 2)

M12x1 socket, 4-pin, D-code

Interface (Power Input)

7/8" plug, 5-pin

Interface (Power Output)

7/8" socket, 5-pin

Interface Slot

8x M12x1 female, 5-pin, A-code

Digital Input Port

16x PNP, 2-type

Digital Output Port 16x PNP

Configurable input/output ports Yes

Total current US, sensor

9.0 A

Total current UA, actuator

9.0 A

Shell material

Zinc, die-cast Size

68 x 37.9 x 224 mm Environmental temperature

-5... 70 °C

Protection level

IP67
