Interface

IO-Link 1.0

Operating Voltage Ub

18 - 30.2 VDC

Interface (COM 1)

M12x1 plug, 4-pin, A-code

Interface slot

8x M12x1 female connector, 5-pin, A-code

Digital input terminals

16x PNP, type 2

Digital output terminals 16x PNP

Configurable input/output ports Yes

Total current US, sensor 4 A

Switching current 16x 500 mA

Total current UA, actuator 4 A

Shell material

Zinc, casting Size

68 x 31.8 x 181.5 mm Environmental temperature

-5... 70 °C

Protection level

IP67, in the state where bolts have been tightened

Transmission rate

COM2 (38.4 kbaud)

Minimum process data cycle 12 ms

Process data input 2 Byte

Process data output 2 Byte
