Interface

Profinet

Auxiliary interface 8x IO-Link

Port level

Specification A

Output current, maximum 2 A

Fast Startup (FSU) Yes

Display

No

Working voltage Ub

18 - 30.2 VDC

Interface (COM 1)

M12x1 socket, 4-pin, D-code

Interface (COM 2)

M12x1 socket, 4-pin, D-code

Interface (Power Input)

7/8" plug, 5-pin

Interface (Power Output)

7/8" socket, 5-pin

Interface slots

8x M12x1 female, 5-pin, A-code

Digital input terminals

16x PNP, 3-type

Digital output terminals 16x PNP

Configurable input/output ports Yes

Total current US, sensor

9.0 A

Total current UA, actuator

9.0 A

Shell material

Die-cast zinc, nickel plating Size

68 x 37.9 x 224 mm Environmental temperature

-5... 70 °C

Protection level

IP67

IO-Link version 1.1

Safety Hub Support

Yes
